Keychron Q1 Max QMK/VIA Wireless Fully Assembled Knob

Keychron Q1 Max QMK/VIA Wireless Fully Assembled Knob

Deskripsi Produk

Temukan Keychron Q1 Max, keyboard mekanikal wireless QMK/VIA yang ditingkatkan dengan koneksi wireless 2.4 GHz dan frekuensi polling 1000 Hz. Desainnya yang dipikirkan matang dilengkapi dengan lapisan busa akustik untuk kualitas suara premium.

Spesifikasi

• Lebar: 145 mm
• Panjang: 327.5 mm
• Tinggi Depan: 22.6 mm
• Tinggi Belakang: 35.8 mm
• Tinggi Kaki: 2.4 mm
• Sudut: 5.2°
• Berat: 1724 g ± 10 g
• Bahan Tubuh: Aluminium
• Bahan Plat: PC

Material dan Kompatibilitas

Keycap KSA double-shot PBT, tidak transparan. Switch Gateron Jupiter. Stabilizer PCB. Backlight RGB. Kompatibel dengan 3 pin & 5 pin MX seperti Gateron, Cherry MX, dan Kailh. Versi siap pakai dengan baterai 4000 mAh.

Performa dan Kompatibilitas

Versi siap pakai dengan MCU ARM Cortex-M4 32-bit STM32F402. Frekuensi polling 1000 Hz (wireless) / 90 Hz (Bluetooth). NKRO Yes. Waktu kerja wireless hingga 180 jam (tanpa backlight). Versi wireless RGB hingga 100 jam. Versi Bluetooth 5.1. Kompatibel macOS/Windows/Linux.

Meet the Keychron Q1 Max, a  full metal QMK/VIA wireless custom mechanical keyboard upgraded with a 2.4 GHz wireless connection, featuring a 1000 Hz polling rate. Elevating the typing experience further, it has been thoughtfully upgraded with multiple layers of acoustic foams, ensuring a premium sound quality with every keystroke.

Specs

Width 145 mm

Length 327.5 mm

Front Height 22.6 mm (without keycaps)

Back Height 35.8 mm (without keycaps)

Feet Height 2.4 mm

Angle 5.2°

Weight 1724 g ± 10 g (Fully Assembled version)

Body Material Aluminum

Plate Material PC

Keycap KSA double-shot PBT keycaps, not shine-through (Fully Assembled version)

Switch Gateron Jupiter (Fully Assembled version)

Stabilizer Screw-in PCB stabilizer

Backlight South-facing RGB LED

Hot-swappable Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc.

MCU ARM Cortex-M4 32-bit STM32F402 (256KB Flash)

Polling Rate 1000 Hz (2.4 GHz & wired) / 90 Hz (Bluetooth)

N-Key Rollover (NKRO) Yes for both wireless and wired modes

Battery 4000 mAh Rechargeable li-polymer battery

Wireless Working Time (Backlit off) Up to 180 hours (Lab test result may vary by actual use)

Wireless Working Time (RGB) Up to 100 hours (Lowest brightness)

Bluetooth Version 5.1

Compatible System macOS/Windows/Linux

Connectivity 2.4 GHz / Bluetooth / Type-C wired

Bluetooth Device Name Keychron Q1 Max

Operating Environment -10 to 50℃
